Introduction of Double Planetary Mixer

The double planetary mixer is a high-performance mixing equipment widely used in various industries. It employs two types of mixers, each rotating on its axis while orbiting around the vessel’s central axis, creating a unique and highly efficient mixing action. This design ensures thorough blending of materials, particularly for viscous and complex mixtures. In addition, due to the equipped vacuum system, it can effectively avoid the generation of bubbles and foam while processing. This type of mixer is especially suitable for mixing, dissolving and mutual reaction from powder to high-viscosity and high-density materials.

Double planetary mixer offers exceptional versatility, making it suitable for applications ranging from pharmaceuticals and cosmetics to food and chemicals. SeFluid’s double planetary mixers are designed with state-of-the-art technology and precision engineering to deliver superior performance and reliability. By choosing SeFluid’s SDPM product series, customers can expect enhanced productivity, reduced downtime, and consistent product quality.

High viscosity double planetary mixer | SeFluid

specification

Mixer Power

2.2-45 kw

Disperser Power

2.2-55 kw

Capacity

15-1000 L/batch

Low Speed

20-42 rpm

High Speed

960-2980 rpm

Viscosity

0-1500k cps

Working Principle of Double Planetary Mixer

The double planetary mixer is a versatile mixing equipment widely used for blending and mixing of materials. Its working principle involves the interaction of two planetary blades within a mixing chamber.

The mixer consists of a centrally located, rotating agitator, known as the “primary blade,” and a second set of blades, called the “satellite blades,” that orbit around the primary blade. Both blades are typically equipped with scraping edges to ensure efficient mixing and scraping of materials from the vessel walls.

During operation, the primary blade rotates on its own axis while simultaneously revolving around the center of the mixing chamber. This motion creates a powerful vortex effect, pulling the materials towards the center of the mixer. At the same time, the satellite blades rotate on their own axes and revolve around the primary blade, ensuring thorough mixing and dispersion of the materials.

The combination of the primary and satellite blade movements results in a unique mixing action. The primary blade provides high-speed agitation, while the satellite blades contribute to the overall blending and dispersion of the materials. Scraping edges of the blades help prevent material buildup on the vessel walls and ensure consistent mixing.

To further enhance mixing efficiency, the mixer can be equipped with various optional features such as high-speed dispersers, vacuum systems, heating or cooling jackets, and different types of vessel designs.

Advantages of Double Planetary Mixer

Double planetary mixers offer several advantages over other mixing equipment, making them a popular choice in various industries. Some of the key benefits include:

Efficient Mixing

The double planetary motion of the blades ensures thorough and uniform mixing, even for high-viscosity materials or those with varying particle sizes.

Versatility

The mixers can handle a wide range of applications, including kneading, dispersing, emulsifying, and homogenizing.

Scalability

Double planetary mixers are available in a wide range of sizes, from small laboratory-scale models to large production-scale machines. This scalability allows for easy adaptation to different batch sizes and production requirements, making it suitable for both small-scale research and large-scale manufacturing.

Optional Features

This type of mixers can be equipped with various optional features to enhance their functionality. These may include high-speed dispersers for additional shear mixing, vacuum systems for degassing or deaeration, heating or cooling jackets for temperature control, and different vessel designs to accommodate specific process requirements.

Sanitary Design

For applications in the food, pharmaceutical, and cosmetic industries, double planetary mixers can be designed with sanitary features such as crevice-free construction and polished surfaces.

Consistent Results

The design of this mixer type ensures consistent and repeatable mixing results. The scraping edges of the blades prevent material buildup on the vessel walls, minimizing product loss and ensuring consistent quality from batch to batch.

Reasons for Choosing SeFluid's Double Planetary Mixer

SeFluid’s double planetary mixer stands out as a top choice for mixing applications in various industries. With its exceptional features and benefits, it offers a superior mixing solution that meets the diverse needs of our customers.

Great Mixing Performance

Our double planetary mixer employs a unique mixing action that ensures efficient blending and dispersion of materials. The combination of the primary and satellite blades provides high-speed agitation and effective material movement, resulting in a uniform and homogenous mixture every time. Even highly viscous or challenging materials can be blended with ease.

Precision and Consistency

At SeFluid, we prioritize precision and consistency in our mixing solutions. Our double planetary mixer is designed to deliver accurate and repeatable results. The scraping edges of the blades prevent material buildup on the vessel walls, minimizing product loss and ensuring consistent quality from batch to batch. By maintaining a high level of control and accuracy, our mixer helps our customers achieve their desired mixing goals consistently.

Customization and Additional Features

We believe in providing tailored solutions to our customers’ specific needs. Our double planetary mixer can be customized with optional features to enhance its functionality. These may include high-speed dispersers for additional shear mixing, vacuum systems for degassing or deaeration, heating or cooling jackets for precise temperature control, and different vessel designs to accommodate unique process requirements. We work closely with our customers to understand their specific needs and provide the most suitable configuration for their applications.

Applications of Double Planetary Mixer

In recent years, double planetary mixer has become necessary equipment in more and more industries. In particular, as the trend of world energy changes, it is used more and more widely in the development of new energy.

New Energy

Various battery slurries and pastes (lithium batteries, nickel-chromium batteries, nickel-hydrogen batteries, fuel cells, power batteries).

Electronics

Solder paste, ceramic slurry, magnetic material, silicone ink, electronic adhesive, pvc plastic, potting glue for electronic and electrical devices, hot melt adhesive.

Chemical

Production of various sealants, silicone sealants, structural sealants, anaerobic adhesives, mold adhesives, synthetic resin rubber, putty and abrasives paste.

Medicine

Various ointments, polymer gels (medical stickers, pediatric antipyretic stickers, cold quick stickers, ice stickers, eye stickers), dental products.

Cosmetics

Production of body cream, lipstick, lotion, gel, mask, mascara, foundation, nail polish, toothpaste, soap and most high viscosity daily chemicals.

Food

Mixing processing of various pastes, paste-like mixtures, seasonings, jams, chocolate syrups and most high viscosity material which is hard for conventional mixer to handle.
